100 - 6000 MHz Low Loss Reflective SP3T Switch


    • General purpose
    • Low insertion loss: 0.6 dB at 2 GHz
    • High input IP3: +55 dBm at 2 GHz
    • CMOS compatible triple voltage control
    • Reflective
    • Standard SMT Package

    Qorvo's TQP4M0011 is a packaged GaAs FET single-pole, three-throw (SP3T) switch with control signals from three independent control bias lines. Signal path (switch) states may be controlled using DC voltages operating from 1.8 to 5 Volts. The TQP4M0011 has 0.1 to 6 GHz broadband performance.

    The TQP4M0011 is packaged in a RoHS-compliant, compact 12-pin 3x3mm QFN package.

    This SP3T switch can be used in wireless infrastructure, test and measurement, or can be used for any general prupose wireless application.


      • Cellular Infrastructure
      • General Purpose Wireless
      • LMR
      • Smart Energy
      • Test and Measurement
      • VHF / UHF Transmission
      • Wireless LAN (WLAN)
    开关类型 SP3T
    吸收式/反射式 Reflective
    频率最小值(MHz) 100
    频率最大值(MHz) 6,000
    插入损耗(dB) 0.6
    隔离(dB) 34
    电压(V) 3.3
    电流(mA) 0.015
    RoHS Yes
    Lead Free Yes
    Halogen Free Yes
    ITAR Restricted No
    ECCN 5A991.B
