QPC0542
0.02 - 50 GHz SOI SPDT Switch
Qorvo's QPC0542 is an ultra-wide band SOI Single-Pole, Double–Throw (SPDT) reflective switch. Operating from 0.02 to 50GHz, the QPC0542 typically supports up to 1W input power handling at control voltages of 0/+3 V. This switch maintains low insertion loss of 2 dB or less and greater than 40 dB isolation at 40 GHz, making it ideal for high isolation switching applications across both defense and commercial platforms. The QPC0542 is offered in a 2.25 x 2.25 mm with Flip-Chip on laminate-based package. This, along with the minimal DC power consumption, allows for easy system integration.
主要特性
- Frequency Range: 0.02 to 50 GHz
- SOI SPDT Switch
- Insertion Loss: <2 dB typcal @ 40GHz
- Power Handling: ≤ 1W
- Isolation: 40dB typical @ 40GHz
- RF Settling Time: < 66ns
- Switching Speed: < 50ns
- Reflective Switch
- Control Voltage: 0/+3V
- QFN Package Dimensions: 2.25 x 2.25 x 0.92 mm
典型应用
- EW
- Test & Measurement
